SoundQubed HDS3.310-D4 10 Inch Car Subwoofer – 1500W RMS Dual 4 Ohm
🔊 Powerful Performance. Upgrade your vehicle's audio system with the SoundQubed HDS3.310-D4 10 inch car subwoofer.
This HDS3.3 Series driver handles 1500 watts RMS and 3000 watts peak power.
Its dual 4-ohm voice coils provide flexible wiring options for compatible car audio amplifiers.
Enjoy powerful bass output for custom installations and high-performance sound systems.
🎵 Sound Quality and Performance
The HDS3.3 Series is designed for demanding low-frequency reproduction.
Its 28.7Hz resonant frequency supports deep bass response in properly designed enclosures.
An 81.2dB sensitivity rating describes its acoustic efficiency.
The 13mm Xmax specification supports controlled cone movement during demanding bass passages.
🛠️ Construction and Design
A 3-inch voice coil supports substantial continuous power handling.
The 160-ounce magnet assembly provides a strong foundation for the motor structure.
Its die-cast aluminum basket delivers rigid structural support.
The 7.2-inch mounting depth requires sufficient enclosure clearance.
🔧 Installation and Compatibility
This dual 4 ohm subwoofer supports parallel and series voice coil wiring.
Parallel wiring produces a 2-ohm final impedance.
Series wiring produces an 8-ohm final impedance.
Choose an amplifier with suitable RMS output at your selected impedance.
Verify mounting clearance, enclosure volume, and vehicle electrical capacity before installation.
⚡ Key Features and Specifications
-
🔊 Brand: SoundQubed
-
📦 Model: HDS3.310-D4
-
📏 Speaker Size: 10 inches
-
⚡ RMS Power: 1500 watts
-
🔥 Peak Power: 3000 watts
-
🔌 Impedance: Dual 4 Ohm
-
🎵 Voice Coil: 3 inches
-
🧲 Magnet Weight: 160 ounces
-
📐 Mounting Depth: 7.2 inches
-
🔉 Resonant Frequency: 28.7Hz
-
🎚️ Xmax: 13mm
-
🛠️ Basket: Die-cast aluminum
🚗 Complete Your Car Audio Upgrade
Explore our Car Speakers Collection for additional speakers and audio upgrades.
Complete your vehicle transformation with professional Car Window Tinting services in Delaware.
❓ Frequently Asked Questions
Can this subwoofer be wired to 2 ohms?
Yes. Parallel wiring produces a 2-ohm load, while series wiring produces 8 ohms.
What amplifier should I use?
Choose an amplifier delivering suitable RMS power at your selected impedance.
Can this subwoofer use a sealed or ported enclosure?
Yes. SoundQubed provides recommended volume ranges for both enclosure designs.
