Features

The 15W1600 offers you an incredible punch to your pro audio system. The 15W1600 loudspeaker will offer you subwoofer type performance while enhancing your mid-bass stability and has a specially designed force air ventilation system to ensure proper cooling for long hard play. The durable spider and woven surround offer precise movement along its impressive 7.6mm Xmax.

Non-pressed pulp cone offers a natural classic tone found in most high-end PA speaker cabinets, making the 15W1600 an ideal woofer or subwoofer option for both ported and sealed speakers.
The upgraded and advanced voice coil and cone material along with its ability to reproduce extremely low frequencies will forever make this your woofer of choice to replace your existing drivers. The large 4 voice coil accepts the abuse of higher power systems while staying cool with the side forced air cooling system.


Highlights

  • Nominal Impedance: 8 Ohms
  • Rated AES Power Handling (RMS): 800 Watts
  • Program Power: 1600 Watts
  • Sensitivity (1W/1m): 97 dB
  • Voice Coil Diameter: 4?


GENERAL SPECIFICATIONS

Nominal Diameter 15? (381 mm)
Nominal impedance 8 Ohms
Rated AES Power Handling (RMS) 800 Watts
Program Power 1600 Watts
Sensitivity 2.83V at 1m 97 dB
Recommended Hi Pass Crossover**
**For Full Power Handling
75 Hz**
**12db Per Octave Crossover
Frequency Response at -10dB 55 2,500 Hz
Voice Coil Diameter 4? (101 mm)
Voice Coil Wire Copper
Voice Coil Winding Depth 18.5 mm
Former Material Kapton
Magnetic Gap Depth 9.0 mm
Frame Material Die Cast Aluminum


THIELE-SMALL PARAMETERS

Equivalent Volume Vas 91.19 l
Excursion (mathematical)*** Xmax 7.0 mm
Free Air Resonance Fs 53.6 Hz
Mechanical Factor Qms 13.77
Electrical Factor Qes 0.44
Total Factor Qts 0.42
Cone Area Sd 984 cm
Mechanical Mass Mms 130.8 g
Bl Factor Bl 24.13 Tm
Dc Resistance Re 5.8 Ohms
Inductance Le 1.78 mH at 1 kHz
Mechanical Mass Without Air Mmd 113.3 g
Mechanical Compliance Cms 0.067 mm/N

***Xmax=(Voice coil winding depth-Magnetic Gap depth)/2+ Mgnetic Gap Depth/4
