PRV Audio 12MR2000-NDY 12" Midrange Loudspeaker Single

Features The new 12MR2000-NDY will sure change the game on vocal reproduction! Features a large 4 CCAW...
Vendor: PRV Audio
SKU: 12MR2000-NDY
Availability: Out Of Stock
$219.91
$219.91
Please hurry! Only 0 left in stock
Limited-Time Offers, End in: 151D 8H 23M 0S
10 customers are viewing this product

Free Shipping

Free standard shipping on most* orders!

PRV Audio 12MR2000-NDY 12" Midrange Loudspeaker Single

PRV Audio 12MR2000-NDY 12" Midrange Loudspeaker Single

$219.91

PRV Audio 12MR2000-NDY 12" Midrange Loudspeaker Single

$219.91

Features

The new 12MR2000-NDY will sure change the game on vocal reproduction! Features a large 4 CCAW inside/out voice coil that results in very high efficiency while providing smooth and accurate Midrange response.



Highlights

  • Nominal Impedance: 8 Ohm
  • Nominal Power Handling: 1000 Watts
  • Continuous Program Power (RMS): 2000 Watts
  • Sensitivity (1W/1m): 98 dB
  • Voice Coil Diameter: 4?



GENERAL SPECIFICATIONS

Nominal Diameter 12? (305 mm)
Nominal impedance  8 Ohm
Nominal Power Handling* 1000 Watts
Continuous Program Power (RMS)** 2000 Watts
Max Peak Power*** 4000 Watts
Sensitivity 2.83V at 1m 98 dB
Recommended Hi Pass Crossover
For Full Power Handling
145 Hz
12db Per Octave Crossover
Frequency Response at -10dB  68 4,800 Hz
Voice Coil Diameter 4? (100 mm)
Voice Coil Wire Copper
Voice Coil Winding Depth 16.8 mm
Former Material Glass Fiber
Magnetic Gap Depth 9.0 mm
Frame Material  Die Cast Aluminum



*Nominal power handling is defined as the maximum RMS power that the speaker can handle in a 2-hour test with a pink noise with 6dB of crest factor and a bandpass filter with 12db/oct tuned in its usable frequency range.
**Continuous Program Power (RMS) is the maximum power that the speaker can handle considering a regular musical program using our recommended filters, this power can be used to define the optimum amplifier power to provide a clean signal without clipping or saturation.
***Max Peak Power is the maximum power operation for the speaker, this power is allowed just for a few fractions of a second, usually found just on the peaks of the music. Keeping this power for a little longer timer will damage the speaker.



THIELE-SMALL PARAMETERS

Equivalent Volume Vas 48.16 l
Excursion (mathematical)*** Xmax 6.15 mm
Free Air Resonance Fs 54.48 Hz
Mechanical Factor Qms 17.61
Electrical Factor Qes 0.35
Total Factor Qts 0.34
Cone Area Sd 573 cm
Mechanical Mass Mms 81.11 g
Bl Factor Bl 22.77 Tm
Dc Resistance Re 6.6 Ohm
Inductance Le 0.69 mH at 1 kHz
Mechanical Mass Without Air Mmd 73.35 g
Mechanical Compliance Cm...
