PRODUCT DESCRIPTION The Ultimate LED replacement headlight option for any vehicle with 7 Sealed Beam lamps. The...
Vendor: Oracle Lighting
SKU: 5769-001
Availability: In Stock
$269.10
$269.10
Please hurry! Only 1 left in stock
Limited-Time Offers, End in: 151D 8H 23M 0S
10 customers are viewing this product

Free Shipping

Free standard shipping on most* orders!

Oracle Lighting 5769-001 - 7" High Powered LED Headlights (Pair) - Black Bezel - White

Oracle Lighting 5769-001 - 7" High Powered LED Headlights (Pair) - Black Bezel - White

$269.10
Oracle Lighting 5769-001 - 7" High Powered LED Headlights (Pair) - Black Bezel - White
Oracle Lighting 5769-001 - 7" High Powered LED Headlights (Pair) - Black Bezel - White
Oracle Lighting 5769-001 - 7" High Powered LED Headlights (Pair) - Black Bezel - White

Oracle Lighting 5769-001 - 7" High Powered LED Headlights (Pair) - Black Bezel - White

$269.10
Description
PRODUCT DESCRIPTION

    • The Ultimate LED replacement headlight option for any vehicle with 7 Sealed Beam lamps. The rugged design is perfect for your Jeep Wrangler, Off-Road Vehicle, Buggies, or Classic Car/ Truck. Installation is very easy with the included H4 and H13 Plug and Play connectors. Each set comes in full color retail-ready packaging and a 2-Year free Replacement Warranty. You can even choose optional colored Halos for even more customization!

      Latest Product Improvements

      Improvements in brightness and reliability by adding a constant current LED driver to the main circuit board inside of the lamp to control the halos.

      NEW! No need for Anti-Flicker Wiring Adapters- The new SMART Integrated Can-Bus system automatically adjusts- preventing flicker issues.

      Increased Reliability- By conditioning the power going into the LEDs this prevents degradation which can shorten the overall lifespan of the product.

      Wider Input Voltage Range- The new SMD Halos can operate on a very wide voltage range from 12V-24V so that voltage spike can not damage the LEDs.

      Brighter LED Halos- by moving the heat load of the resistors off the PCB we are able to increase the number of LEDs on the circuit board without thermal issues.

       LED chips upgraded from a Cree LED to a Phillips Luxeon ZES chip. They deliver a very high efficacy 130LM/W ratio while having lower thermal output.



    • To fit these Lights to JL Wrangler or JT Gladiator you will need

      Product Features: (Per Light)
      - Low Beam Wattage: 30W Normal/36W Max
      - Low Beam Lumens: 2200 Lumens/3600 Raw Lumens
      - High Beam Wattage: 40W Normal/48W Max
      - High Beam Lumens: 3600 Lumens/4800 Raw Lumens
      - Color Temperature: 6000K (Cool White Color)
      - Input Voltage of Light: 12-24V DC
      - Input Voltage of Halo (If Included): 12V DC
      - Current Draw: 2.50 Amps @ 12V DC / 1.30 Amps @ 24V DC
      - Optional: ORACLE Halo Rings Pre-Installed
      - Premium Performance Phillips Luxeon ZES LEDs
      - Die-Cast Housing with Corrosion Resistant Coating
      - Heavy Duty Solid State Electronics
      - Hard-coated Polycarbonate Lens
      - Wide Beam Pattern with Sharp Cut-Off Line
      - Easy Plug & Play Installation
      - DOT and SAE Certified
      - 2 year

      We Recommend Matching Fog Lights


    • In the Box:
      - (2) ORACLE Lighting 7" High Powered LED Headlights with Black Bezel
      - H4/H13 Connectors










    • Wiring for Halos:
      Red Wire is (+) the positive wire
      Black Wire is (-) the negative wire

      For Halo Colors White and Amber (Road Legal Colors) we recommend:
      Connecting wires to the Parking Light Harness
      Connecting wires to Ignition Power

      For other Single Colors (Non Road Legal Colors) we recommend:
      Connecting Wires to a Toggle Switch Connecting Wires to a ControllerFor ColorSHIFT Halos:
      Connect wires directly to the ColorSHIFT Controller you purchased

    • ORACLE PART# COLOR/OPTION
      5769-504 NO HAL...

      PRODUCT FEATURES & SPECIFICATIONS


    • To fit these Lights to JL Wrangler or JT Gladiator you will need

      Product Features: (Per Light)
      - Low Beam Wattage: 30W Normal/36W Max
      - Low Beam Lumens: 2200 Lumens/3600 Raw Lumens
      - High Beam Wattage: 40W Normal/48W Max
      - High Beam Lumens: 3600 Lumens/4800 Raw Lumens
      - Color Temperature: 6000K (Cool White Color)
      - Input Voltage of Light: 12-24V DC
      - Input Voltage of Halo (If Included): 12V DC
      - Current Draw: 2.50 Amps @ 12V DC / 1.30 Amps @ 24V DC
      - Optional: ORACLE Halo Rings Pre-Installed
      - Premium Performance Phillips Luxeon ZES LEDs
      - Die-Cast Housing with Corrosion ..

      		•
