Features

Low Noise Pre-Amp Circuitry:

• Low voltage signal from the source unit comes into the amplifier pre-amplifier circuit with minimal distortion

Inputs:

• Nickel-Plated RCA jacks create best connection and resist corrosion

Hi Level Inputs:

• Hi level inputs with small connecting adapter for the highest sound quality connection

Operation Mode:

• Switched 2, 4 or 5 channel mode)

Equalizer:

• CH1/2 - Switched Full / High Pass Filter (HPF) 40Hz-500Hz
• CH3/4 - Switched Full / High Pass Filter (HPF) 40Hz-500Hz
• CH5 Low Pass Filter (LPF) 45Hz-160Hz

Class / Topology:

• Class A/B + Class D

Output Devices Technology:

• Pulse Width Modulated (PWM) MOSFET power supply provides stable power through the PC board with minimal heat generation

Heat Sink:

• Classic aluminum Hifonics design to minimize heat build up on the Pro-Fi output devices

Power Supply:

• Simpatico Coil Design The dual coil Pulse Width Modulated power supply keeps voltage constant through the Ultra-Fi output devices

Output Connections

• Preamp RCA outputs to daisy chain multiple amps eliminate additional signal cables from the source unit

Connections Type:

• Molded / angled secure connection for all system wires for ease of access during installation

Bass Remote:

• Wired Bass Remote allows adjustments to bass frequencies from the control which can be mounted anywhere in the vehicle. Smooth potentiometer and ringed illumination in a satin black mount create a custom look

Full-Range RCA Outputs for Signal Pass Through

• Daisy chain multiple amplifier to eliminate additional signal cables from the source unit

LED System Protection Circuitry Diagnostics

• 3-way protection circuitry with LED power (green) and protect (red) indicators monitor thermal, overload, DC, and speaker short protection with lighted indicators on the amplifier end panel

Bass Remote Included

• Wired Bass Remote allows adjustments to bass frequencies from the control which can be mounted anywhere in the vehicle. Smooth potentiometer and ringed illumination in a satin black mount create a custom look

Phase Adjustment

• CH5 Phase 0-180 Degrees
• Bass drum attack, snap requires phase between deep frequency subwoofers and upper midbass speakers
• Fat man/Skinny man, must arrive at your ear at the same time or bass sounds muddy

Parametric / Signal Contouring

• ParaQ Parametric Bass EQ with adjustments: Boost (0-10dB) Width (Narrow-Wide (On Center) Center Frequency (30Hz - 100Hz)
