When your audio demands excellence, precision, and serious volume, these loudspeakers answer with authority. Built for passionate audio enthusiasts and professionals alike, this high-performance component offers the clarity, durability, and strength required for competitive sound systems and customized vehicle installations.
This driver isn’t just loudspeakers—it’s crafted to project with unmatched definition. Whether you're building a multi-speaker system or fine-tuning your mobile audio layout, the CRX-700AL steps up with power and reliability. It adds immersive sound to every area of your car with a 1000-watt program power and 500-watt RMS handling.
🔊 A Game-Changer for Car Audio Loudspeakers
Standard vehicle sound systems often fall short when it comes to producing clean, dynamic output at higher volumes. That’s where premium loudspeakers, like the CRX-700AL loudspeakers, stand out. Designed for pro-level performance, it provides a frequency response range that reaches deep into upper registers without distorting the signal.
Whether you’re showcasing your system at an audio meet or enhancing your daily drive, this driver ensures your audio setup turns heads and pleases ears.
💪 Built for Performance and Durability
The CRX-700AL loudspeaker driver is engineered with performance and longevity in mind. Key features include:
-
Power Handling: 500W RMS and 1000W peak, supporting demanding audio applications
-
Impedance: 8Ω for flexible integration into custom and pro audio systems
-
Sensitivity: 106 dB (1 W/1 m), delivering high-output sound with minimal input
-
Voice Coil: 2" aluminum coil (51.6mm), copper-clad and heat-resistant
-
Diaphragm: Reinforced titanium construction for clarity and durability
-
Magnet: Ferrite material for stable, consistent output
-
Mounting Depth: Compact 60mm depth for versatile vehicle installations
Each material was chosen for a specific reason—whether it’s temperature resistance, projection power, or signal purity—giving you a driver that performs under pressure.
🧠 Optimized for High-Frequency Clarity
One of the standout qualities of the CRX-700AL is its exceptional response range. With a frequency response spanning 1000 Hz to 19,000 Hz (and up to 20,000 Hz in box settings), it captures the brilliance of vocals, instruments, and effects with surgical accuracy.
That precision makes it ideal for mid-to-high frequency roles in a multi-speaker environment. It’s a natural complement to powerful subwoofers and balanced tweeters, helping complete a professional-grade audio spectrum.
🚗 Versatile Installation Across Custom Systems
The CRX-700AL isn’t limited to one type of build—it’s ideal for a wide range of vehicle audio configurations. From show cars to street cruisers, this driver mounts easily and blends seamlessly into various setups:
-
Custom dash pods and A-pillars
-
Rear decks and show-stage builds
-
Multi-speaker wall arrays
-
Pro-grade motorcycle or off-road audio kits
Its compact size and frontal screw mounting system provide a solid fit without compromising on sound projection. This makes it perfect for installations where space is limited but audio quality is critical.
🛠️ Professional Installation Makes the Difference
Installing loudspeakers and drivers like the CRX-700AL requires precision to unlock their full potential. We recommend working with certified installers for optimal sound staging, amplifier matching, and crossover tuning. Visit our Car Audio & Video Installation page to find support for advanced audio system setups.
Professional tuning ensures this compression driver delivers the cleanest highs and tightest imaging possible, elevating your overall audio experience.
🌞 Complement with Style and Comfort
A high-performance sound system deserves a sleek, cool environment. While you're upgrading your loudspeakers, consider enhancing your vehicle’s comfort and style with window tinting services in Delaware. Window tints reduce glare, lower cabin heat, and give your ride a polished look to match your powerful sound system.
📦 Technical Specifications Summary
| Feature |
Specification |
| Program Power |
1000 Watts |
| Rated AES Power (RMS) |
500 Watts |
| Nominal Impedance |
8Ω |
| Sensitivity (1W/1m) |
106 dB / In-box: 110 dB |
| Frequency Response |
1000–19000 Hz |
| Voice Coil Diameter |
2" (51.6mm) |
| Voice Coil Wire |
ALW |
| Magnet Material |
Ferrite |
| Diaphragm Material |
Titanium |
| Mounting Depth |
60 mm |
| Exit Throat Diameter |
2" (50.8mm) |
| Nominal Diameter |
135 x 60mm |
❓ Frequently Asked Questions
Q1: Do I need an external amplifier for this loudspeaker?
Yes. To achieve optimal performance and reach the power capacity, a dedicated amplifier is highly recommended.
Q2: Is this compression driver compatible with home audio systems?
While designed for mobile and automotive use, it can be integrated into custom home setups with proper impedance matching and enclosure design.
Q3: Can I pair this loudspeaker with a subwoofer?
Absolutely. It’s an excellent mid-to-high frequency driver that pairs well with subwoofers to complete your soundstage.
🏁 Final Word
The CRX-700AL compression driver represents the pinnacle of professional-grade loudspeakers in automotive audio. Built to withstand high temperatures, vibration, and intense usage, it provides a perfect balance of clarity, durability, and power.
If you're aiming to build an audio system that not only sounds incredible but lasts, the CRX-700AL is the upgrade your loudspeaker array deserves.
