AudioControl LC-4.800

4-channel car amplifier — 125 watts RMS x 4

You want power?

The key to building a great car stereo system is power with control. AudioControl's LC-4.800 4-channel amplifier generates 125 watts RMS per channel, so it'll drive even the most demanding aftermarket speakers with plenty of headroom to spare. And it'll rumble the low end too — bridge this versatile amp's output and you've got 400 watts per channel on tap to get your subs bumping.

Control is key

When it's time to dial in the sound, you've got plenty of control. Highly adjustable crossover networks let you set your high- and low-pass filters precisely, and AudioControl's celebrated AccuBASS circuit ensures maximum bass performance, whether you're connected to an aftermarket or factory stereo. The optional ACR-1 wired remote lets you control the volume from your front seat. Onboard LEDs indicate optimized signal flow for inputs and outputs, plus give you a warning when a source is too loud and causing distortion.

Add kick to your factory stereo

AudioControl designed the LC-4.800 to work equally well with aftermarket and factory stereos. Six active speaker-level inputs allow you to connect to almost any factory radio, while signal summing accommodates the separate bass, midrange, and treble signals in some amplified factory systems. AudioControl's GTO™ Signal Sense circuitry turns the amp on automatically whenever it senses a signal coming from the speaker-level inputs.

Product highlights:

4-channel car amplifier

125 watts RMS x 4 at 4 ohms (200 watts RMS x 4 at 2 ohms)

400 watts RMS x 2 bridged at 4 ohms (4-ohm stable in bridged mode)

variable Linkwitz-Riley high- and low-pass filters (30-300 Hz, 12 dB/octave)

AccuBASS® circuitry for improved bass response

MILC™ (Maximum Input Level Control) LED optimization and clip indicators

GTO™ (Great Turn On) signal-sensing turn-on

Other Features:

speaker-level inputs (summable up to 6 channels)

preamp inputs and outputs

optional wired remote level controller (#161ACR1) available

fuse rating: 40A x 2

4-gauge power and ground leads recommended — wiring and hardware not included with amplifier

dimensions: 9"W x 2-1/8"H x 7-13/16"D

warranty: 5 years

MFR # 851-018-0

What's in the box:

4-Channel amplifier

Two 40-amp ATO fuses (installed)

2 Large Phoenix connectors (installed)

3 Small Phoenix connectors (installed)

2.5mm Allen wrench

Quick Start Guide
